ProductsSMC Directional Control Valves Rotary Actuators/Air Grippers Modular F.R.L. Air Cylinders Vacuum Equipment Fittings/Tubing Switches/Sensors/Controller Air Preparation Equiptment PANASONIC Schneider PVC plate HP APC EOCR Automatic Fire Fighting Equipment View Classification Fittings for General Purposes Product Name Fittings for General Purposes Series Name Contents ∎ Characteristic . One-touch Fittings KQ2 ・Possible to use in vacuum to –100 kPa.・Body type: Totaled 51 models・Thread material/Surface treatment(Treated or Non-treated): 2 types・Selectable surface treatment: Brass(No plating), Brass + Electroless nickel plated・Applicable tubing O.D. Round Type Metric: ø2, ø3.2, ø4, ø6, ø8, ø10, ø12, ø16 Inch:ø1/8'', ø5/32'', ø3/16'', ø1/4'', ø5/16'', ø3/8'', ø1/2'' Oval Type Metric: ø3.2, ø4, ø6 Inch:ø1/8'', ø5/32'', ø3/16''・Connection thread Metric:M3, M5, M6 R,Rc :1/8, 1/4, 3/8, 1/2 G:1/8, 1/4, 3/8, 1/2 NPT:10-32UNF, 1/16, 1/8, 1/4, 3/8, 1/2 Uni:1/8, 1/4, 3/8, 1/2・Seal method Sealant/Gasket seal Face seal Gasket seal(Uni thread)The production of the conventional KJ/KQ2 has been discontinued, and the model has changed to the New KQ2. Grease-free (-X17, -X29, -X39) and rubber material FKM (-X34, -X94) specifications are available with the current models. Metal One-touch Fittings KQB2 ・Compact and lightweight・Fluid temperature: −5 to 150℃・Brass parts: Electroless nickel-plated・Grease-free.Rotary One-touch Fittings KS/KX ・Applicable to use for oscillating and rotating sections in robots・Low torque rotation type rotary One-touch fittings・Copper-free (Electroless nickel-plated). Rotary One-touch Fittings KS ・Applicable to use for oscillating and rotating sections in robots・Low torque rotation type rotary One-touch fittings・Copper-free (Electroless nickel-plated). One-touch Fittings Manifold KM ・Compact manifold piping is possible.. Insert Fittings KF ・Vacuum 1.3 x 10-2 kPa applicable・Piping can be done without removing the nut.・Fluid temperature: −5 to 150℃ (Brass sleeve) −5 to 60℃ (Resin sleeve)・Steam can be used.・Grease-free. Miniature Fittings M ・Compact and doesn't require tools for connection・Compact piping space・Hose nipple, Hose elbow, Barb. Self-align Fittings H/DL/L/LL ・Applicable for use on soft copper steel pipes・Flared ridge metal ferrule. Self-seal Fittings KC ・One-touch installation and removal・Built-in self-sealing mechanism・Air does not exhaust after the removal of tubing.・Copper-free (Electroless nickel-plated).Low Torque Rotary Joint MQR ・Metal seal type・Supplies air to the rotary/pivot shafts of turntables and robot arms・Low rotational torque: 0.003 to 0.50 N・m or less・Operating temperature: −10 to 80℃・Allowable rpm: 200 to 3000 min-1 (rpm).Rubber Seal Rotary Joint MQR-X229 ・Rubber seal・Oldham coupling・Operating pressure range: −100 kPa to 0.7 MPa・Allowable rpm: 200 min−1 (rpm) *1・Max. start-up rotation torque: 0.50 N・m*2 or less・Service life: 10 million rotations*3・Number of circuits: 8 circuits*1 Reference value*2 When no pressure is applied*3 Under SMC's life test conditions. ∎ Attachments Tag List
